Sawmill Equipment For Sale

NEDERMAN S-750 BAG FILTER Dust Collector. The NEDERMAN S-Series Baghouse Dust Collector is quick to install and easy to operate. With a 7.5 HP motor and a 4,500 CFM @ 6" WG it's the ideal solution for the small shop or single work-cell operation. -- Specifications: 7.5 HP - 1,750 RPM TEFC Motor, (24) Beane material filter bags and magnetic starter. -- Features: 243 Sq/ft of filter media, easy installation, typically (1) hour; quiet operation, (3) waste discharge points. Inlet opening 11". -- Available in 208/230 or 480 V, 60 Cy, 3 Ph. Must specify voltage at the time of orderAvailable options:42 Gallons Drum Discharge - Single Drum (3 REQUIRED)230 Gallon Dump Bin

NEDERMAN - DANTHERM NFK3000 8+2 Filter Dust Collection System. Full-Featured with Return Air, Abort Gate, Non-Return Explosion Valve, Spark Detection, and Rotary Air Lock with Dual Relay Transfer Fan., 40,000 CFM approx Capacity set up @ 6.3 to 1 air-to-cloth ratio, (design dependant). Consistsf of (8) filter modules under positive pressure and (2) entry (dust fallout modules), expandable Heavy Duty Baghouse Dust Collector System. Designed for medium to large-sized air flows with large material concentration (dust loading).Features: Variable Speed motor drive. (2) 32" High Speed Abort Gates and (2) 32" Explosion Isolation Flap Valves CARZ - Nederman. 2-Zone Spark Detection for (2) Process Air Lines to Filter and (2) Return Air Lines.- Zone 1 Spark Detection – 2 x extinguishing sets in 28"; duct to be located a minimum of 23’ from detector set in 40"; duct between fan and dust collector- Zone 2 Spark Detection – 2 x 32"; high speed abort gates to be located in minimum of 10’ from zone 2 detector sets in 40"; duct.Specifications: -- Total approx. 7,320 sq. ft.of filter area, total of (400) filter bags. Each module contains (50) filter bags @ 915 sq. ft. filter area per module). -- Consists of (8) Filter module sections with combined explosion and access door in each section, each with 2 HP regenerative fans for cleaning of filter media. -- Unit is ATEX rated. Hopper for collected material to a NRSZ-10 Rotary Air Lock (RAL) discharging into a Dual Relay System dust transfer with T.40-315 Relay Fan – 20 HP -- Equipped with: (1) Ground-mounted 200 HP - 1800 RPM TEFC direct drive motor with Variable Frequency Drive and NEDERMAN 40" Material Handling Fan package with 40" inlet pipe to fan inlet box. -- Electrical: NFKZ Control Panel. Separate control panel with motor starter for main blowers. -- Complete with: Support stand (separate steel support) is not included. .Drain with plug: quick open access doors, (dual purpose Explosion Relief Doors) and inlet flange; -- Includes: Approx. 40" Trunk line pipe filter header to fan inlet, square to round fan discharge adaptor, and approx. 3' high support steel structure. -- Baghouse dimensions are: 94.5" square (2,400 x 2,400 mm) for each module.Hence approx. shell overall length is 945" (78.75'). Depth is 94.5". Height of baghouse shell is approx. 167" (4,250 mm), not including support legs. -- Actual model is NFK3000-8HJ-2BL

NEDERMAN S-1000 BAG FILTER Dust Collector. The NEDERMAN S-Series Baghouse Dust Collector is quick to install and easy to operate. It's the ideal solution for a smaller shop or single work-cell operation.Specifications: -- With a 10 HP motor and a 5,000 CFM @ 7" WG and 360 Sq/ft of filter media. -- 10 HP - 1,750 RPM TEFC Motor, (24) Beane material filter bags and magnetic starter. -- Features: Easy installation, typically (1) hour; quiet operation, (3) waste discharge points. Inlet opening 16". Available in 208/230/460 V, 60 Cy, 3 Ph. Must specify Voltage at time of orderAvailable option:- Aluminum Impeller: - 45 Gallon Drum Discharge - Single Drum (3 REQUIRED)- 230 Gallon Dump Bin: Available spare parts:- Filter Bag (24 Filters)- Plastic Bags (Roll of 90 - 8 mil thickness) - 500mm Clamp (bags, barrels, and bin)

Power Voltage (V) 208-230/460 Frequency (Hz) 60 No of phases 3 Filter type Bag Number of filter elements 24 Filter material Superbag Weight (lbs) 100 Power (Hp) 10.0 (7.5 Kw) Note 5000 CFM at 7.0" Wg All Pipe

Used NYB fan , series 20 GI, 38” wheel, 21” inlet, 50HP 50 HP, other HP motors available The fan has been primed & repainted in Feb. 2025 Inlet diameter: 21-1/2” Outlet size: 20-1/2” X 17” Wheel size & type: 364 DH Wheel Diameter: 38” +-, Shop Number: B12787 Year: 2007 P.O. # 15745 Disc.: UB ROT: CW,. We have other fans available Dust cyclones are also available A Video of fan running is available We provide a wooden pallet for shipping Shipping dimensions--without pallet: 80” wide x 64” long x 63” tall detached fitting Weight with pallet: 1,800 LBS, Contact us for a freight rate.

New York Blower Company Series 20 GI Fan Fan Size 29 DH Good Condition

NEW YORK BLOWER - 362 PLR: General Purpose Air Handling Fan -- Flat backward inclined blade. General Purpose fans are suited for moist & mildly contaminated air in industrial-plant ventilation, dust collection (clean air side) and process-air, comercial-institutional ventillation applications. -- 50 HP; 1,180 RPM NEMA premium Inverter Capable Motor. -- Rated at 21,600 CFM @ 5" Static Pressure, 1132 RPM,(Max 1360), 23.3 BHP, and air density 0.075 Lbs/cubic foot. Class II. -- 56.9 AMPS @ 460 V; 60 Cy; 3-Phase. -- Size 36 PLR, Wheel dia.,36.5". Outlet area 7.66sq. f ((40.75x 20.5") approx 40" inlet dia. -- 40" x 27" Flanged outlet. -- Dimensions/Weight: 71" L x 70" W x 68" H; Weight: 1,200 Lbs.

NEW YORK BLOWER Fan - 304AF-40: Centrifugal Blower/Motor; approx. 21,000 CFM @ 30"; SP NEW YORK BLOWER. -- Complete with: 200 HP direct drive motor; 3,565 RPM; 460 Volt; "444TS" frame. -- Backward Inclined; high pressure Airfoil Wheel; NYB "AF-40" Fans: Extend the pressure capabilities of backward inclined fan designs to the higher pressures found in heavy industrial process applications such as: Boiler forced-draft; combustion air; solvent recovery; recirculating air. -- Owner states: This fan is unused. -- Weight: 2,664 Lbs.

New York Blower Company 36" Pressure Blower, 15hp Baldor electric motor, fan direct mount on motor

New York Blower Co. Shop# R13016-100, Size 407RTS, 26" Inlet & Outlet, 60HP Motor, RTS Fan.

NYB GP Size 182 Bloer with Electric Motor

NYB 28" Blower

Newman Shaving Mill Already pulled out of service and ready to ship.

Newman G200 Knife Grinder

NEWMAN Trimmer System. Model KNO 24. Will trim 8' to 16' with adjustable '0' saw. Trimmer includes 7.5 HP motors on each saw with aluminum wheel hold downs; saw blades; chain type waste conveyor in trimmer; electric variable speed feed chains. System includes: 5 strand lumber deck with 81X chain by 13' long with lumber stops; 4 strand tipple to discharge boards when raised; 6' x 5 strand board dealer with 5 dealer wheels to feed boards to trimmer; 25' long x 30" wide lumber belt under tipple; 30' x 24" waste belt from trimmer waste chain. NOTE: Equipment loaded on your truck and  located in Biscoe, NC. Price $28,900.00. OBO

These machines were purchased new and removed from the current production line for a large hammermill. Ready to load. No conveyor available. - Newman SS24 - Two machines available. - 100 HP Motor on 600 V. Can be changed to 480 V.

Newman K 2S Double End Trimmer

Newman Whitney RH Drop Saw Trimmer

Newman K-20 Double End Trim Saw Adjusts up to 16'
